ARB Air Compressors at Just Differentials
ARB Air Compressors at Just Differentials
We stock all of the different ARB Air Compressors at Just Differentials, from the compact all the way up to the dual. There are many different options for actuating your air lockers and filling tires. You can also choose between 12 and 24 volt, based on the power system you have in your vehicle. These compressors aren't just for vehicles that are equipped with ARB Air Lockers, they are useful if you need to inflate air bags, fill tires, power air horns or do just about anything else that requires onboard air.
This compact vehicle mounted Air Locker Air Activation System has been specifically designed to provide on-board air for activating ARB Air Locker locking differentials. A smaller unit, it comes with a mounting bracket that allows versatile positioning and is sealed for moisture and dust resistance with quality components used for reliable compressed air and extra long life.
Voltage 12 Volts
Current Draw No Load 5 Amps
Current Draw Under Load 6.5 Amps
Air Flow No Load .88 CFM
Air Flow Under Load .47 CFM
Weight 5.3 Lbs
Duty Cycle 35%
Size 4.8" Height, 6.4" Length, 3.5" Width
Permanently mounted, this compressor is installed into your truck and includes a full wiring loom with air locker solenoid plug in contacts, mounting hardware with reinforcing bracket and quality compressor isolating switch.
So what makes this compressor special? It's small enough to fit into even the tightest space and quiet enough to mount in the cab. It has enough output to air up four 35" - 37" tires in a single duty cycle and typically airs up a 35" tire in just over two minutes. And, it works. We've tested this unit in ovens, freezers, underwater and in the silty dust of the Simpson Desert and it continues to perform.
Voltage 12 Volt
Current Draw- Load/ No Load 22.9/ 13 Amps
Air Flow- Load/ No Load 2.18/ 2.65 CFM
Size- Inches 5.6 x 7.5 x 3.8
Duty Cycle 50%
Weight 10 lbs.
Manufacturer ARB
Warranty 2 Year
ARB's new CKMTA12 twin on-board compressor kits were designed to fill the market need for a compact sized yet high-volume compressed air source to suit the high volume airflow needs of most air powered tools, and also to suit the actuation and control needs of the ARB Air Locker, and the harsh and demanding environment of the ARB Air Locker user.
Voltage 12 Volt
Current Draw- Load/ No Load 50/ 28 Amps
Air Flow- Load/ No Load 4.65/ 6.16 CFM
Size- Inches 4 x 7.5 x 10.8
Duty Cycle 100%
Weight 20 lbs.
Manufacturer ARB
Warranty 2 Year
Find all the different options, including the 24 volt and portable compressors online: ARB Air Compressors
Last edited by justdifferentials; 02-09-2015 at 02:28 PM.
